FIAT 600 D

Quotes

BrandModelEngine sizeYearPrice
FIAT600 D7671960-694000.00

Technical information

Engine
Positionposteriore
Time4
Availability4 cilindri verticali in linea
Cylinder bore and stroke (mm)62 x 63,5
Engine size (cm³)767
Compression ratio7,5 : 1
Maximum power (DIN)32 CV a 4800 g/min
Maximum torque (SAE)5,5 kgm a 2800 g/min
Max rev. (g/min)4800
Specific power (CV/l)41,7
Cylinder blockghisa
Cylinder headlega leggera
Drive shaft support3
Valves2 per cilindro,in testa, in linea, con aste e bilancieri
Camshaft1, laterale
Lubricationpompa a ingranaggi, filtro centrifugo e a cartuccia in derivazione
Circuit capacity (l)4,5
Fuel1 carburatore Weber o Solex,inverito, monocorpo, tipo 28 ICP o 28 PIV-2
Fuel additivepompa meccanica
Coolingaqua
Transmission
Drive wheelsposteriori
Clutchmonodisco a secco
Type of transmissionmeccanico
Gears4 + RM
Synchronised gearsII, III, IV
Transfer gear ratios (I) 3,385, (II) 2,055, (III) 1,333, (IV) 0,896,(RM) 4,275
Gear stickcentrale
Reduction torqueconica, spirale
Ratio4,875 : 1
Chassis
Bodyportante
Front suspensionruote indipendenti, quadrilateri deformabili, braccio inferiore a balestra trasversale, ammortizzatori telescopici
Rear suspensionruote indipendenti, bracci triangolari oscillanti, molle elicoidali, ammortizzatori telescopici
Performance
Max speed (km/h)110
in first gear (km/h)30
in second gear (km/h)45
in third gear (km/h)70
in fourth gear (km/h)110
Weight/power ratio (Kg/CV)18,1
Payload (Kg)320
Maximum climb angle (%)30
Direct drive speeda 1000 giri/min: 22,7 km/h
Body
Typeberlina
Doors2
Passenger capacity4
Seatsanteriori separati
Electric system
Voltage12
Battery32
Dynamo230
DistributorMarelli
Lights2 anteriori
Size and weight
Pitch (mm)2000
Front wheel track (mm)1150
Rear wheel track (mm)1160
Maximum length (mm)3295
Maximum width (mm)1380
Maximum height (mm)1405
Minimum distance from ground (mm)145
Dry weight (Kg)580
Weight distribution38% asse anteriore, 62% asse posteriore
Turning line (m)4,6
Wheel size3,5
Tyres5,20 - 12
Tank capacity (l)27
Steering and breaks
Double enveloping wormvite e settore elicoidale
Turns lock-to-lock2,12
Brakestamburo
Braking surface (cm²)anteriore 216 , posteriore 216
Practical guidelines
Fuelbenzina
Motor oil3 l, sost. ogni 5000 Km
Gear oil1,5
Valve rocker clearancespiraz. 0,15 mm e scarico 0,15 mm
Tyre pressureanteriori 1,2 atm, posteriori 2,1 atm
Spark plug heat ranges225
